    Guardian Fall Protection

    Xcalibre Fall Arrest Block 3M Webbing

    SKU: HS-01-001-0001

    The FAB3W is a lightweight palm size Fall Arrest Block and is so light it can be mounted directly to the users harness via the rear D connector.  Also available as a dual assembly for 100% tie off whilst moving between anchorages whilst moving around a structure.



    In stock
    Picture of Xcalibre Fall Arrest Block 3M Webbing Xcalibre Fall Arrest Block 3M Webbing £120.18

    Detailed Description

    Rapid Lock-On: The brake activates quickly under the acceleration of the user and triggers the Pawl to lock onto the shaft.

    Webbing & Shaft: One piece shaft supports the Dyneema & Polyester webbing which has a minimum breaking load of 15kN.

    PC/ABS Housings With Grips: High strength housings give protection to the mechanical assembly and include TPE grips to both sides.

    Shock Pouch: The shock pouch reduces peak shock loads to less than 6kN and extends to varying amounts depending on the fall conditions.

    Dual Adaptor: A simple coupler connects two FAB3W’s which can be mounted on the rear "D" of a full body harness giving the user two attachment points for greater safety in the workplace.

    Fall Indicating Swivel Hook: The swivel hook includes a fall indicator, which clearly shows if the device has been subjected to a shock load.

    Features & Benefits

    • 3M working length
    • Max user weight 150Kg
    • Compact, sleek and modern design
    • Anchorage karabiner as standard
    • Lightweight 1.1Kg including swivel hook
    • Composite housing UV stabilised
    • Soft TPE side grips
    • Internal steel chassis
    • Acceleration activated brakes
    • Ultra fast lock on nominal 100mm
    • Alloy swivel hook as standard
    • Fall indicator via webbing pouch
    • Polyester webbing MBL 23kN
    • PTFE Roller lowers friction and drag
    • Fully serviceable
    • Tested for vertical and horizontal use
    • EN360 ANSI OSHA AS/NZS 1891.3:1997
