Monitoring Accessories
- Suitable for Leica, Icon and GeoMax
- 180 degree capability.
- 25mm shaded prism.
- Works in 90% of conditions, including rain.
- Patented removable back plate.
- Attaches to all surfaces! Glue, screw & magnetic.
- 250 metre range.
- Robust.
- It’s unique features include both 90° and 45° facets.
- 2 highly reflective target areas.
- Stable mounting.
- Works with Bullhead and Flat-bottom rail types.
- Suitable for Topcon, Trimble and Sokkia
- 180 degree capability.
- 25mm shaded prism.
- Works in 90% of conditions, including rain.
- Patented removable back plate.
- Attaches to all surfaces! Glue, screw & magnetic.
- 250 metre range.
- Robust.
Made of galvanised reinforcing steel with turned 12mm LECIA attachment plugs. Great value for money as no additional adapter is needed
Aluminum housing for wall mounting mini prism during long term monitoring projects.
Size: 150 x 30 x 40mm. 2 No 8mm countersunk fixing holes.
Prism is included.
Galvanised Steel monitoring brackets for attaching CMP104, GMP104 and GMP004 to the rail.
A tightly sprung bracket with toothed underside provides a non-slip attachment to the rail.
11R2-40 Wall Anchor
A brass expansion sleeve with a PVC plastic coating for high visibility. M8 female thread. Head diameter: 30mm. Length: 40mm. Shank diameter: 12mm.
11R2-30W Wall Anchor
A brass expansion sleeve with a PVC plastic coating for high visibility. M8 female thread. Head diameter: 30mm. Length: 30mm. Shank diameter: 12mm.
11R2-ST Allen key for fixing 11R-bolts
The GEO-XR single point rod settlement system is used to monitor sub-surface settlement or heave of ground.
The system comprises a series of inner steel rods and plastic outer sleeves together with plates when positioned on ground before fill or Borros type anchors when used in boreholes.
