    Master B 360 111kW Direct Oil Heater

    SKU: CC-03-003-0047

    These portable direct oil fired heater offers one of the most efficient and reliable all-round heating and drying solutions of any unit of this type and style on the market.

    Back

    £2099.00

    In stock
    Master B 360 111kW Direct Oil Heater Main Master B 360 111kW Direct Oil Heater £2099.00

    Detailed Description

    This extremely efficient 111kW oil heater features a lightweight chassis, oil and suction filters and an oil tank level indicator.

    These direct space heaters can also be attached to external analog or digital thermostats to give operators even more control over the area temperature.

    This portable heater boats high air displacement, an electric control panel, IP44 protection, a thermally protected motor, an electronic flame control with photocell, a trolley and a snorkel. All of these features come as standard with this model.

    The trolley feature allows for ease of movement in and between site work, the thermally protected motor ensures safe operation and with a massive air flow of 3300m³/h and a tank capacity of 105l, this high-performance space heater is the ideal application for large industrial applications.

    The new B series heaters are equipped with a TH5 room thermostat socket (available separately - optional) and a fuel level indicator. In addition, the housing has an additional upper and lower embossing, which strengthens the structure and stiffens it, preventing deformations and extending the life of the housing.

    Please note:

    Ventilation of the room is necessary to prevent a deficiency of oxygen when using this product.

    Features & Benefits

    • Overheat thermostat
    • Post ventilation
    • Thermally protected motor
    • Transparent external suction filter
    • Three oil filters – oil pump filter, suction filter and inlet filter
    • Electronic flame control with photocell
    • Stainless steel combustion chamber
    • Oil tank with level indicator
    • Trolley included
    • Snorkel
    • Easy maintenance with external pump
    • Diagnostic LED
    • Nozzle
    • Electrode
    • Fuel pump filter Danfoss
    • Suction filter
    • Suitable For Building Sites & Well Ventilated Areas
    • Runs on Diesel or Kerosene

    Technical Specification

    Length (mm)
    1600
    Width (mm)
    700
    Height (mm)
    940
    Weight (kg)
    84-105
    Type
    Space Heater
    Output (kW)
    111
    Voltage
    230V
    Thermostat
    Built-in
    Installation
    Portable
    Ductable
    No
